DC - Main switch; ON/OFF switch; 1-pole; 0-I; Panel mounting 4-hole; Padlock Device; black, electric gray
Product information "DC - Main switch; ON/OFF switch; 1-pole; 0-I; Panel mounting 4-hole; Padlock Device; black, electric gray"
DC - Main switch; ON/OFF switch; 1-pole; 90°; 0-I; four hole panel mounting; Front side IP40; 20 A; Padlock Device; black, electric gray
| Switch type: | G20 |
|---|---|
| Rated continuous current lu/lth: | 20 A |
| AC-3, 3-phase, 3-pole, 380 - 440V: | 2,2 kW |
| AC-23A, 3-phase, 3-pole, 380 - 440V: | 3 kW |
| Switching programme: | TD3201 |
| Name: | G20.TD1201/01.E |
| Type of contact development: | ON/OFF switch |
| Installation described: | four hole panel mounting |
| No. of poles: | 1 |
| Mounting unit: | E |
| Type of installation: | Panel mounting |
| Detailed installation type: | Panel mounting 4-hole |
| Switch disconnector IEC60947-3: | Y |
| Faceplate color: | electric gray |
| Handle Color: | black |
