ON/OFF switch; 3-pole; Base mounting/DIN rail mounting; Auxiliary Contact; NO 1; NC 1
Product information "ON/OFF switch; 3-pole; Base mounting/DIN rail mounting; Auxiliary Contact; NO 1; NC 1"
ON/OFF switch; 3-pole; 90°; two hole base mounting; Front side IP40; 32 A; 7,5 kW (AC-3, 380 - 440 V); 11 kW (AC-23A, 380 - 440 V); Auxiliary Contact; NO 1; NC 1
| Switch type: | KG32A |
|---|---|
| Rated continuous current lu/lth: | 32 A |
| AC-3, 3-phase, 3-pole, 380 - 440V: | 7,5 kW |
| AC-23A, 3-phase, 3-pole, 380 - 440V: | 11 kW |
| Switching programme: | T303 |
| Name: | KG32.T203/NL-EXRC.*KNBOX |
| Type of contact development: | ON/OFF switch |
| Installation described: | two hole base mounting |
| No. of poles: | 3 |
| Mounting unit: | VE |
| Type of installation: | Base mounting |
| Detailed installation type: | Base mounting/DIN rail mounting |
| Switch disconnector IEC60947-3: | Y |
| Faceplate color: | brushed aluminum |
